8 Input Analog Multiviewer with Looping Inputs

Features:

• Input Looping capabilities - for further distribution or duplication of inputs
• Single frame processing delay
• 8 auto-detect PAL / NTSC composite with passive input loop
• 4 channels of discrete audio per input (optional)
• Supports DVI, HDMI, VGA (optional), SDI (optional) outputs
• Supports full 10-bit HDMI 1.3 outputs
• Output resolution up to 2048 x 1080 (including 1080p)
• Built-in CATx extenders - extend 1080p (DVI/HDMI) up to 115 feet with optional active receivers
• Built-in analog and digital clocks for time of day and up/down counters
• Built-in LTC timecode and NTP for clock synchronization
• Multiple labels per video windows - UMD, OMD, IMD, standalone labels
• Supports Serial/IP and GPI tally
• Automatic input aspect ratio detection
• Built-in video, audio alarm detections - no audio, audio high/low, no video, video black, video frozen, WSS/AFD
• Apantac Skin technology allows on-screen graphical elements to be customized with any graphics tools
• Field upgradable to allow discreet audio (AES/AA)
• Front panel headphone jack with volume adjustment for convenient audio monitoring
• Front panel buttons for quick preset recalls
• 1RU with optional redundant power supply
• 3 year limited warranty
